BIPV Roof Tiles

Name: BIPV Roof Tiles
Brand: Wuxi EVO New Energy Tech. Co., Ltd.

by Wuxi EVO New Energy Tech. Co., Ltd. · China

Technology: PERC, TOPCon, BIPV Our company has been working on BIPV lines in 10 years more. Including research, design and manufacturing. Our products has been widely used in some projects in verious of building. Let these buildings achieved perfect integration. It is realized the integration with architecture of building and bringing continuous solar energy to the peoples.

PERC145 W15% eff20-Year Product Warranty

0Upvotes

Overview

Key Specifications

Max Power

145 W

Efficiency

15%

Product Warranty

20 years

Dimensions

740 × 375 mm

Connectors

MC4

Max System Voltage

1500 V

Launch Year

2026

Price

—

Full Specifications

Product Identity

NameBIPV Roof Tiles

ManufacturerWuxi EVO New Energy Tech. Co., Ltd.

CountryChina

CategoryPERC

Cell TypeMonocrystalline

Number of Cells8

Electrical Parameters (STC)

Model	Pmax (W)	Vmpp (V)	Impp (A)	Voc (V)	Isc (A)	Eff (%)

Mechanical Characteristics

Dimensions740 × 375 × 13 mm

Weight6 kg

Front GlassTempered

Back Glass

Frame

Junction BoxIP 67

Output Cables4 mm2

ConnectorsMC4

Mechanical Load0 Pa

Operating & Temperature

Operating Temperature-40°C to 85°C

Max System Voltage1500 V DC

Max Series Fuse Rating10 A

Power Tolerance0 ~ +3.5 %

NMOT47±2 °C

Temp Coeff Pmax-0.5141 %/°C

Temp Coeff Voc-0.391 %/°C

Temp Coeff Isc0.0814 %/°C

Warranty

Product Warranty20 years

Power Warranty25 years (80% at year 25)

Certifications & Regions

Certifications—

RegionsAsia-Pacific

CountriesChina

Commercial

Price—

Launch Year2026

AvailabilityAvailable
