PiK 530-550M(110)
by PiKCELL Group · North Macedonia
Visit siteTechnology: Bifacial, PERC
PERC550 W21% effBifacial
0Upvotes
Overview
Technology: Bifacial, PERC
Key Specifications
Max Power
550 W
Efficiency
21%
Product Warranty
10 years
Dimensions
2384 × 1096 mm
Connectors
Max System Voltage
1500 V
Launch Year
2026
Price
—
Full Specifications
Product Identity
NamePiK 530-550M(110)
ManufacturerPiKCELL Group
CountryNorth Macedonia
CategoryPERC
Cell TypeMonocrystalline
Number of Cells110
Electrical Parameters (STC)
| Model | Pmax (W) | Vmpp (V) | Impp (A) | Voc (V) | Isc (A) | Eff (%) |
|---|
Mechanical Characteristics
Dimensions2384 × 1096 × 30 mm
Weight33 kg
Front Glass
Back Glass
Frame
Junction BoxIP 68
Output Cables
Connectors
Mechanical Load0 Pa
Operating & Temperature
Operating Temperature-40°C to 85°C
Max System Voltage1500 V DC
Max Series Fuse Rating35 A
Power Tolerance0 ~ +1 %
NMOT44±2 °C
Temp Coeff Pmax-0.34 %/°C
Temp Coeff Voc-0.25 %/°C
Temp Coeff Isc0.04 %/°C
Warranty
Product Warranty10 years
Power Warranty25 years (81.4% at year 25)
Bifacial Output (Rear-side Power Gain)
Certifications & Regions
Certifications—
RegionsGlobal
CountriesNorth Macedonia
Commercial
Price—
Launch Year2026
AvailabilityAvailable
