Green Energy
太阳能板
280

280

来自 Jiaxing Fuying Composite Materials Co., Ltd. · China

BIPV 280W Technology: Thin film We are China double glass modules manufacturers and custom PV solar panels factory, The company is committed to building a composite functional film, PVB double glass photovoltaic module application demonstration, and promotion base, and a PVB research institute, forming a marketing center, industry conference center, product display, and a PVB composite functional film and photovoltaic product manufacturing base.

Other280 W效率 20%
0

概览

BIPV 280W Technology: Thin film We are China double glass modules manufacturers and custom PV solar panels factory, The company is committed to building a composite functional film, PVB double glass photovoltaic module application demonstration, and promotion base, and a PVB research institute, forming a marketing center, industry conference center, product display, and a PVB composite functional film and photovoltaic product manufacturing base.

关键规格

最大功率

280 W

效率

20%

产品质保

12 年

尺寸

2089 × 1033 mm

连接器

MC4

最大系统电压

1500 V

发布年份

2025

价格

—

完整规格

产品标识

名称280
厂商Jiaxing Fuying Composite Materials Co., Ltd.
国家China
类别Other
电池片类型Thin film
电池片数量0

电气参数（STC）

型号Pmax (W)Vmpp (V)Impp (A)Voc (V)Isc (A)效率 (%)
28028027.1410.3232.6810.9920%

机械特性

尺寸2089 × 1033 × 5 mm
重量25 kg
正面玻璃Tempered
背面玻璃Tempered
边框Anodized Aluminium
接线盒IP 68
输出线缆300 / 4 mm2
连接器MC4
机械载荷5400 Pa

工作与温度

工作温度-40°C to 85°C
最大系统电压1500 V DC
最大串联保险丝16 A
功率公差-3 ~ +3 %
NMOT45 °C
Pmax 温度系数-0.35 %/°C
Voc 温度系数-0.28 %/°C
Isc 温度系数0.04 %/°C

质保

产品质保12 年
功率质保25 年（第 25 年保持 80%）

认证与地区

认证—
地区Asia-Pacific
国家/地区China

商业信息

价格—
发布年份2025
供货状态Available
